Processors SKU:BX8071512400

Description

Processor
Processor cores 6
Cooler included N
Processor threads 12
Processor operating modes 64-bit
Box Y
Processor cache type Smart Cache
Processor boost frequency 4.4
Processor manufacturer Intel
Processor family Intel Core i5-12xxx
Processor socket LGA 1700
Performance cores 6
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 76.8
Processor codename Alder Lake
Processor cache 18
Processor model i5-12400
Performance-core boost frequency 4.4
Performance-core base frequency 2.5
Processor base power 65
Maximum turbo power 117
Bus type DMI4

Graphics
Discrete graphics adapter N
Discrete graphics adapter model Not available
On-board graphics adapter Y
On-board graphics adapter base frequency 300
On-board graphics adapter DirectX version 12.0
On-board graphics adapter OpenGL version 4.5
On-board graphics adapter refresh rate at maximum resolution (DisplayPort) 60
Number of execution units 24
On-board graphics adapter maximum resolution (HDMI) 4096 x 2160
On-board graphics adapter refresh rate at maximum resolution (HDMI) 60
Number of displays supported (on-board graphics) 4
On-board graphics adapter model Intel UHD Graphics 730
On-board graphics adapter maximum resolution (eDP – Integrated Flat Panel) 5120 x 3200
On-board graphics adapter outputs supported Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1
On-board graphics adapter dynamic frequency (max) 1450
On-board graphics adapter maximum resolution (DisplayPort) 7680 x 4320
On-board graphics adapter refresh rate at maximum resolution (eDP – Integrated Flat Panel) 120
On-board graphics adapter ID 0x4692 / 0x4682
Multi-Format Codec Engines 1

Technical details
Status Launched
Target market Gaming
OpenCL version 2.1
Launch date Q1’22

Memory
Maximum internal memory supported by processor 128
Memory channels Dual-channel
Memory types supported by processor DDR4-SDRAM,DDR5-SDRAM
Memory bandwidth (max) 76.8

Features
Harmonized System (HS) code 8542310001
Execute Disable Bit Y
Idle States Y
Thermal Monitoring Technologies Y
Supported instruction sets SSE4.1,SSE4.2,AVX 2.0
Scalability 1S
CPU configuration (max) 1
Embedded options available N
Market segment Desktop
Maximum number of PCI Express lanes 20
Export Control Classification Number (ECCN) 5A992CN3
Commodity Classification Automated Tracking System (CCATS) G167599
Use conditions PC/Client/Tablet
PCI Express configurations 1×16+1×4,2×8+1×4
PCI Express slots version 5.0,4.0
Direct Media Interface (DMI) Revision 4.0

Operational conditions
Tjunction 100

Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Y
Intel® Turbo Boost Technology 2.0
Intel® AES New Instructions (Intel® AES-NI) Y
Enhanced Intel SpeedStep Technology Y
Intel VT-x with Extended Page Tables (EPT) Y
Intel 64 Y
Intel Virtualization Technology (VT-x) Y
Intel Virtualization Technology for Directed I/O (VT-d) Y
Intel® Quick Sync Video Technology Y
Intel® Clear Video HD Technology (Intel® CVT HD) Y
Intel® Secure Key Y
Intel® Optane™ Memory Ready Y
Intel® OS Guard Y
Intel® Boot Guard Y
Intel® Speed Shift Technology Y
Intel Turbo Boost Max Technology 3.0 N
Mode-based Execute Control (MBE) Y
Intel® Deep Learning Boost (Intel® DL Boost) Y
Intel® Volume Management Device (VMD) Y
Intel® Control-flow Enforcement Technology (CET) Y
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Y
Intel® Thread Director N

Packaging data
Package type Retail box

Other features
Maximum internal memory 128
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1

Weight & dimensions
Processor package size 45 x 37.5
